Product Descriptions:
- Safety : Standard with OPS and SAS safety management system, improve the safety level.
- Stability :Strong chassis and mast increases durability.
- High efficiency and energy-saving : CAN bus main wire and full AC control system, which greatly improves the motor performance and lower the electricity consumption.
- High adaptation : Suspension design on driving assembly makes it perfect performance on all kinds of floor.
- Easy to maintenance : Half-closed electric unit chamber design and battery side out function make it easy for maintenance work.
- Comfortable operation : Equipped with EPS function and multifunctional finger joysticks bring you unmatched comfort.
Full Specifications:
| Manufacturer | Zowell | |||||
| Model | RRE115 | |||||
| Power | Electroc | |||||
| Operator Type | stand | |||||
| Load Capacity | Q | ib.(kg) | 3200 lbs(1450 kg) | |||
| Load Centre | c | in.(mm) | 23.6″(600mm) | |||
| Load Distance | forks retracted | x | in.(mm) | 12.6″(287mm) | ||
| Wheel Base | y | in.(mm) | 64.96″(1650mm) | |||
| Truck Weight | less battery | ib.(kg) | 8466 lbs(3840kg) | |||
| Axle loading(Front/Rear) (/) | W/O Load,forks retracted | ib.(kg) | 4336 lbs(1967kg)/6,069 lbs(2753kg) | |||
| With Load,forks extension | ib.(kg) | 8139 lbs(3692kg)/5463 lbs(2478kg) | ||||
| With Load,forks retracted | ib.(kg) | 10716 lbs(4861kg)/2885 lbs(1309kg) | ||||
| Tyre Type | poly | |||||
| Tyres | power unit side,drive | in.(mm) | 13.5″×2.9″(φ343mm×140mm) | |||
| Tyres | load side | in.(mm) | 5.0″×5.5″(φ127mm×74mm) | |||
| Castor Wheel | in.(mm) | 8.0″×4.0″(φ200mm×100mm) | ||||
| Wheels | no.(x=driven) power unit side/load side | 1x,2/4 | ||||
| Track Width | power unit side | b10 | in.(mm) | 31.5″(800mm) | ||
| Fork Carriage Tilt | forward/backward / | angle | ° | 3/4 | ||
| Mast | collapsed height | h1 | in.(mm) | 140″(3556mm) | ||
| Free Lift | h2 | in.(mm) | 104″(2642mm) | |||
| Lift Height | h3 | in.(mm) | 321″(8150mm) | |||
| Mast | extended height w.load backrest | h4 | in.(mm) | 357″(9068mm) | ||
| Overhead Guard Height | h6 | in.(mm) | 95″(2413mm) | |||
| Outtrigger Height | standard wheel | h8 | in.(mm) | 5.1″(130mm) | ||
| Headlength | l2 | in.(mm) | 63.1″(1604mm) | |||
| Overall Width | power unit side | b1 | in.(mm) | 42.9″(1098mm) | ||
| Fork Dimension | th×w×l | in.(mm) | 40/100/1070 | |||
| Fork Carriage | 2A | |||||
| Fork Carriage Width | incl.load backrest | b3 | in.(mm) | 32.44″(824mm) | ||
| Width Across Forks | b5 | in.(mm) | 7.9″-30.2″(200-768mm) | |||
| Inside Straddle | in 25mm increments | b4 | in.(mm) | 34″-50″(865-1270mm) | ||
| Reach | l4 | in.(mm) | 40.5″(1030mm) | |||
| Ground Clearance | centre wheelbase | in.(mm) | 1.97″(50mm) | |||
| Working Aisle Width | 1200×1000 deep | Ast | in.(mm) | 119″(3023mm) | ||
| Working Aisle Width | 1000×1200 deep | Ast | in.(mm) | 123.3″(3132mm) | ||
| Working Aisle Width | 800×1200 deep | Ast | in.(mm) | 121.6″(3088mm) | ||
| Turning Radius | Wa | in.(mm) | 74.6″(1895mm) | |||
| Overall Length | length over outriggers | l7 | in.(mm) | 82.4″(2094mm) | ||
| Backrest Height | in.(mm) | 62″(1576mm) | ||||
| Entry Step Height | in.(mm) | 10.2″(260mm) | ||||
| 3rd Post | in.(mm) | 1″(25mm) | ||||
| Travel Speed | w./w.o. load power unit first /- | km/h | 10/10 km/h | |||
| forks first /- | 10/10 km/h | |||||
| Lift Speed | w./w.o. load / | m/s | 0.33/0.5 m/s | |||
| Lower Speed | w./w.o. load / | m/s | 0.5/0.5 m/s | |||
| Reach Speed | m/s | 0.3 | ||||
| Brakes | Electric | |||||
| Traction Motor | 60 min.rating | kw | 6kw | |||
| Lift Motor | 15% on time | kw | 13kw | |||
| Max.Battery Box Size | l×h×w | mm | 413×985×788 | |||
| Battery Voltage | nominal capacity 5h rating | V/Ah | 36 V/775Ah | |||
| Battery Weight | minimum | kg | 1940 lbs(880kg) | |||
| Type of Controller | traction/lift/steering // | |||||
