The special energy-saving and dust-proof air conditioner for the printing factory can save 50% of electricity immediately!
Reduce costs and increase profits, starting with energy-saving and dust-proof air conditioning.
The factory can save 50% electricity and increase 10% profit, which is the most effective way to reduce costs and increase efficiency.
Main Specifications:
Model: DKKFR100II cold and warm type
Rated refrigerating capacity | 100KW | Rated heating capacity | 70KW |
Rated refrigerating power | 18KW | Heating rated power | 18KW |
Cooling current | 38A | Heating current | 36A |
Anti touch type | CLASS I | Waterproof grade | IPX4 |
Refrigerant | R22 | Circulating air volume | 10000m³*2 |
Overall weight | 2500kg | Rated power supply | 380V/3PH/50HZ |
External dimensions | 2650*1590*2860mm | Internal dimensions | 1200*830*1950mm |
Model: DKKF100II single cooling type
Rated refrigerating capacity | 90KW | Fan power | 4.4KW |
Rated refrigerating power | 19KW | Water pump power | 0.75KW |
Cooling current | 38A | Heating current | 46A |
Anti touch type | CLASS I | Waterproof grade | IPX4 |
Refrigerant | R22 | Circulating air volume | 10000m³*2 |
Overall weight | 1950kg | Rated power supply | 380V/3PH/50HZ |
External dimensions | 1450*2050*2100mm | Internal dimensions | 1200*850*1780mm |
product description
Evaporative cooling, dust-proof, energy-saving central air conditioner
The high-efficiency evaporative condenser makes full use of the physical principle of water evaporation and heat absorption. The system formed by the evaporative condenser has low condensation temperature, which makes the compressor run with low power and power consumption. The COP value can reach more than 4.7 (the COP value of ordinary air-cooled heat pump air conditioner is 2.3), which can realize energy-saving operation of the compressor.
The throttled low-pressure liquid refrigerant absorbs heat and evaporates, further reducing the inlet air temperature. The two- stage cooling improves the comprehensive energy efficiency of the air conditioning system (the comprehensive refrigeration cop can reach about 4.7), which saves 50% energy compared with the traditional air-cooled air conditioning.
The return air of the indoor unit of the air conditioning system is filtered by double- layer filter screen and wet curtain. Different particles of dust are filtered by stages to protect the cleanness of the evaporator and ensure the heat exchange efficiency and system life.
According to the dust, paper wool and powder particle diameter of the printing and packaging industry, different mesh filters are designed to achieve effective filtration.
